BatteryProtect 12/24V-100A

Safeguard your battery with the Victron BatteryProtect 12/24V-100A. Automatically disconnects non-essential loads to prevent deep discharge and ensure reliable performance.

Automatic Voltage Detection: 12/24V auto-ranging capability. High Current Capacity: Handles up to 100A. System On/Off Switch: Includes on/off input for system control. Remote Control Input: Offers additional control options. Compact Design: Easy to install in various applications.
£70.80 £54.89 SAVE £15.91
or pay interest-free installments
Klarna
PayPal
Add to Wishlist
SKU: BPR000100400
AVAILABLE IN 7-10 DAYS
Product Details

The Victron BatteryProtect 12/24V-100A is designed to protect your battery from excessive discharge by disconnecting non-essential loads before the battery voltage drops to a level that could cause damage. This ensures that there is always enough power to start the engine or maintain critical systems.

This model features 12/24V auto-ranging capability, allowing it to automatically detect system voltage. It offers a wide voltage range of 6.5 to 35 VDC, making it suitable for various applications, including off-grid systems, marine, and RV setups.

The BatteryProtect can be used as a system on/off switch and includes an on/off input for this purpose. It also features a remote input for additional control options. The device is compact and easy to install, ensuring reliable performance in demanding environments.

Dimensions: 59 x 42 x 115mm

Weight: 0.6 kg

Product Specifications

Technical Specifications

Combined for SKUs: BPR000100400

Alarm Output Delay: 12 s

Alarm Terminal: Screw terminal 3-pole

Battery And Load Terminals: M8 bolts

Battery Voltage Nominal: 12V or 24V (automatic detection)

Bluetooth: No

Current Consumption When Off: 0.6 mA

Current Consumption When On: 1.5 mA

Default Threshold Disengage12: 10.5 V

Default Threshold Disengage24: 21 V

Default Threshold Engage12: 12 V

Default Threshold Engage24: 24 V

Depth: 115 mm

Height: 59 mm

Load Disconnect Delay: 90 s

Load Reconnect Delay: 30 s

Maximum Continuous Load Current Rating40: 100 A

Maximum Continuous Load Current Rating60: 60 A

Maximum Load Alarm Output: 50 mA

Operating Voltage Range: [6, 35] V

Peak Current Rating: 600 A

Protection Category Connection Area: IP00

Protection Category Electronic Components: IP67

Protections: Output short-circuit

Remote On Off Terminal: Yes

Remote Terminal: Screw terminal two pole

Reverse Current: No

Weight: 0.5 kg

Width: 42 mm

Source: Victron
