Victron MPPT 150/35 – SmartSolar Charge Controller – Tr

The Victron SmartSolar MPPT 150/35 Charge Controller is a high-efficiency solar charge controller designed for 12V, 24V, 36V, and 48V battery systems. It features ultra-fast Maximum Power Point Tracking (MPPT), Bluetooth connectivity for remote monitoring, and a VE.Direct port for system integration. With a maximum input voltage of 150V and a charge current of 35A, it's suitable for various solar applications, including off-grid, marine, and backup systems.

MPPT optimised for efficient solar charging. Monitor performance and settings remotely via Bluetooth. For 12V/24V/36V/48V systems. 150V maximum voltage from the solar. 35A maximum current from the solar. Revive completely "dead" batteries. Dimensions: 130 x 186 x 70mm Weight: 1.25kg
£165.00 £110.89 SAVE £54.11
or pay interest-free installments
Klarna
PayPal
Add to Wishlist
SKU: SCC115035210
IN STOCK
Receive between -

Frequently Bought Together

  • Victron MPPT 150/35 – SmartSolar Charge Controller – Tr
Total price:£165.00 £110.89
  • This item: Victron MPPT 150/35 – SmartSolar Charge Controller – Tr £165.00 £110.89
Product Details
Efficient Solar Power Harvesting:
The Victron MPPT 150/35 SmartSolar charge controller optimally harvests power from solar panels, intelligently charging your leisure batteries and preventing overcharging for enhanced battery protection.

SmartSolar Functionality for Control:
Benefit from SmartSolar functionality, enabling wireless connectivity to the Victron Connect app via Bluetooth. Adjust settings and monitor performance conveniently over time for a seamlessly controlled solar charging experience.

Fast and Intelligent Charging Technology:
Using the latest MPPT technology, the charge controller maximizes solar energy harvest, achieving a full charge in the shortest possible time. It also maintains battery health, extending overall battery life. The MPPT 150/35 model handles a maximum input voltage of 150V and a maximum input current of 35A.

MPPT Technology Advantage:
MPPT technology constantly monitors solar panel voltage and current output, efficiently extracting maximum power even in partially clouded or changing light conditions. Recommended for applications like campervans, boats, and off-grid tiny houses due to superior efficiency compared to PWM charge controllers.

Intelligent Load Output and Battery Maintenance:
The intelligent load output function prevents battery damage from excessive draining, with configurable voltage settings. The innovative BatteryLife feature ensures a 100% recharge attempt daily, adjusting disconnect voltage during poor weather to maintain battery health and extend its lifespan.

Convenient Connection Points:
Equipped with Tr screw terminal connection points, the charge controller simplifies the connection process. Strip input and output wires and fix them securely to the screwed terminal for a reliable and user-friendly setup.
Product Specifications

Electrical Specifications

  • Battery Voltage: 12 / 24 / 48 V Auto Select (36V requires software tool)
  • Rated Charge Current: 35 A
  • Nominal PV Power (12V): 500 W
  • Nominal PV Power (24V): 1000 W
  • Nominal PV Power (36V): 1500 W
  • Nominal PV Power (48V): 2000 W
  • Maximum PV Open Circuit Voltage: 150 V absolute maximum coldest conditions / 145 V start-up and operating maximum
  • Maximum PV Short Circuit Current: 40 A
  • Maximum Efficiency: 98%
  • Self-Consumption: 12V: 20 mA / 24V: 15 mA / 48V: 10 mA

Charging & Algorithms

  • Charge Algorithm: Multi-stage adaptive
  • Pre-programmed Algorithms: Eight selectable via rotary switch
  • Programmability: Fully programmable charge algorithm via software
  • Charge Voltage 'Absorption' (Default): 14.4 / 28.8 / 43.2 / 57.6 V (Adjustable)
  • Charge Voltage 'Float' (Default): 13.8 / 27.6 / 41.4 / 55.2 V (Adjustable)
  • Temperature Compensation: -16 / -32 / -64 mV/°C
  • Temperature Sensing: Internal sensor included; optional external battery sensing via Bluetooth (using Smart Battery Sense or BMV-712)

Protection & Environmental

  • Electronic Protection: Over-temperature and power derating, PV short circuit, PV reverse polarity, and PV reverse current protection.
  • Operating Temperature Range: -30°C to +60°C (Full rated output up to 40°C)
  • Humidity: 95%, non-condensing
  • Cooling: Natural convection (No cooling fan)

Mechanical Specifications

  • Dimensions (H x W x D): 130 x 186 x 70 mm
  • Weight: 1.25 kg
  • Enclosure Colour: Blue (RAL 5012)
  • Power Terminals: 16 mm² / AWG6
  • Protection Category: IP43 (electronic components), IP22 (connection area)
  • Data Communication Port: VE.Direct (for wired connection to GX products, PC, or other devices)

Standards & Compliance

  • Safety: EN/IEC 62109-1, UL 1741, CSA C22.2
  • Data Logging: Internal storage for up to 46 days of trend data, including battery voltage, current, temperature, PV voltage, and PV current.
