Victron SmartSolar MPPT 150/60-Tr

The Victron SmartSolar MPPT 150/60‑Tr is a high performance solar charge controller with a 60 A battery current rating, automatic 12/24/36/48 V battery voltage detection, built-in Bluetooth for wireless monitoring and VE.Direct communication for system integration.

High charging capacity: up to 60 A and supports 12/24/36/48 V battery systems Ultra-efficient: >98% conversion, maximising energy harvested from solar panels Wireless and wired connectivity: Bluetooth via VictronConnect plus VE.Direct port Robust build: natural cooling, advanced protection, suitable for demanding conditions Dimensions: 185 x 250 x 95mm Weight: 3kg
£613.20 £250.00 SAVE £363.20
or pay interest-free installments
Klarna
PayPal
Add to Wishlist
SKU: SCC115060211
IN STOCK
Receive between -
Product Details

The Victron MPPT 150/60 SmartSolar Charge Controller is a high-performance solar charge controller designed to intelligently collect and convert solar energy into power for your electrical system. With advanced MPPT (Maximum Power Point Tracking) technology, this charge controller optimizes energy harvest, ensuring a full charge in the shortest possible time. Ideal for various off-grid applications such as campervans, boats, and tiny houses, the MPPT 150/60 model boasts a maximum input voltage of 150V and a maximum input current of 60A.

Key Features:

MPPT Technology:
Constantly monitors the voltage and current output of solar panels.
Maximizes power extraction, especially in changing light conditions.
Highly efficient compared to PWM charge controllers.


Intelligent Charging:
Achieves a full charge quickly and intelligently for optimal battery health.
Extends battery life by implementing smart charging algorithms.


Maximum Input Parameters:

Maximum input voltage: 150V.
Maximum input current: 60A.
Smart Functionality:
Equipped with Bluetooth for wireless monitoring through the VictronConnect App.
Enables remote monitoring of solar charge performance via smartphones (Android and iOS).


Load Output and BatteryLife Feature:
Intelligent load output prevents battery damage by disconnecting the load during low battery conditions.
Configurable voltage settings for load disconnection to prevent excessive battery drain.
BatteryLife feature attempts a 100% recharge daily, adjusting disconnect voltage during poor weather to maintain battery health.


Tr Screw Terminal Connection Points:
Features Tr screw terminal connection points for secure input and output wire connections.
Requires stripping the insulation from the wires for attachment to the screwed terminal.


Versatile Applications:
Suitable for a wide range of off-grid applications, including campervans, boats, and tiny houses.
Efficiently operates in partially clouded skies and changing light intensity.


Efficiency and Performance:
Offers superior efficiency compared to traditional PWM charge controllers.
Maximizes power utilization from solar panels.

Product Specifications

Electrical Specifications

  • Battery Voltage: 12 / 24 / 48 V Auto Select (36 V requires software tool)
  • Rated Charge Current: 60 A
  • Nominal PV Power (12 V): 860 W
  • Nominal PV Power (24 V): 1720 W
  • Nominal PV Power (36 V): 2580 W
  • Nominal PV Power (48 V): 3440 W
  • Maximum PV Open Circuit Voltage: 150 V (absolute maximum coldest conditions), 145 V (start-up and operating maximum)
  • Max. PV Short Circuit Current: 50 A
  • Maximum Efficiency: 98%
  • Self-Consumption: Less than 35 mA @ 12 V / 20 mA @ 48 V

Charge Settings & Algorithm

  • Charge Algorithm: Multi-stage adaptive (eight pre-programmed algorithms) or user-defined
  • Absorption Voltage (Default): 14.4 / 28.8 / 43.2 / 57.6 V (Adjustable)
  • Float Voltage (Default): 13.8 / 27.6 / 41.4 / 55.2 V (Adjustable)
  • Equalization Voltage (Default): 16.2 / 32.4 / 48.6 / 64.8 V (Adjustable)
  • Temperature Compensation: -16 mV / -32 mV / -64 mV / °C
  • Internal Temperature Sensor: Included (compensates absorption and float charge voltage for temperature)
  • Battery Recovery Function: Initiates charging even if the battery has been discharged to zero volts; can reconnect to a fully discharged Li-ion battery with integrated disconnect.

Connectivity & Features

  • Bluetooth Smart Built-in: Wireless setup, monitoring, updates, and synchronization.
  • VE.Direct Port: For a wired data connection to GX devices, PCs, or other equipment.
  • Parallel Operation: Up to 10 units can be synchronized via Bluetooth.
  • Remote On/Off: Yes (2-pole connector); can connect to a VE.Bus BMS.
  • Programmable Relay: DPST (AC rating: 240 VAC / 4 A; DC rating: 4 A up to 35 VDC, 1 A up to 60 VDC).
  • Data Storage: Stores 46 days of historical trend data (battery voltage, current, temperature, PV voltage, and PV current).
  • Optional Display: Compatible with the SmartSolar pluggable LCD display (not included).

Mechanical & Enclosure

  • PV Terminals: 35 mm² / AWG2 (Tr screw terminals)
  • Battery Terminals: 35 mm² / AWG2
  • Dimensions (H x W x D): 185 x 250 x 95 mm
  • Weight: 3 kg
  • Protection Category: IP43 (electronic components), IP22 (connection area)
  • Color: Blue (RAL 5012)

Environmental & Standards

  • Operating Temperature Range: -30 to +60 °C (Full rated output up to 40 °C)
  • Humidity: 95%, non-condensing
  • Maximum Altitude: 5000 m (Full rated output up to 2000 m)
  • Safety Standards: EN/IEC 62109-1, UL 1741, CSA C22.2
  • Electronic Protections: PV reverse polarity, Output short circuit, and Over-temperature protection.
