Victron SmartSolar MPPT 150/85-Tr VE.Can

The Victron SmartSolar MPPT 150/85-Tr VE.Can is a high-performance solar charge controller designed for off-grid applications, featuring advanced MPPT technology and VE.Can communication for efficient energy management.

High Efficiency: Advanced MPPT technology ensures optimal energy harvest. Wide Voltage Range: Supports PV input voltages up to 150V. VE.Can Communication: Seamless integration with Victron systems. Flexible Battery Compatibility: Works with lithium, AGM, gel, and flooded batteries. Remote Monitoring: Monitor and configure via VictronConnect app.
£792.00 £406.80 SAVE £385.20
or pay interest-free installments
Klarna
PayPal
Add to Wishlist
SKU: SCC115085411
AVAILABLE IN 7-10 DAYS
Product Details

The Victron SmartSolar MPPT 150/85-Tr VE.Can is engineered to deliver optimal solar energy storage for off-grid applications. Utilising advanced MPPT (Maximum Power Point Tracking) technology, it ensures maximum energy harvest from your solar panels, even in challenging conditions.

With a wide PV input voltage range of up to 150V, this controller offers flexibility in system design. The VE.Can communication interface allows seamless integration with other Victron components, enabling comprehensive system monitoring and control.

Compatible with various battery types, including lithium, AGM, gel, and flooded batteries, the SmartSolar MPPT 150/85-Tr VE.Can adapts to your specific energy storage needs. Remote monitoring and configuration are made easy through the VictronConnect app, providing real-time insights and control at your fingertips.

Ideal for off-grid solar systems, this charge controller ensures efficient energy management and reliable performance, making it a valuable addition to your renewable energy setup.

Product Specifications

Technical Specifications

Combined for SKUs: SCC115085411

Battery Voltage Auto Select: 12V / 24V / 48V Auto Select (software tool needed to select 36V)

Bluetooth: Yes

Charge Algorithm: Multi-stage adaptive (adjustable)

Charge Voltage Absorption: 14.4V / 28.8V / 57.6V (adjustable)

Charge Voltage Float: 13.8V / 27.6V / 55.2V (adjustable)

Colour: Blue (RAL 5012)

Data Communication: VE.Direct,VE.Bus,Bluetooth

Data Retention Period: 46 d

Data Stored: Battery voltage,Battery current,Battery temperature,PV voltage,PV current

Depth: 103 mm

Environmental Condition: Indoor, unconditioned

Height: 216 mm

Max Altitude: 5,000

Max Efficiency: 98 %

Max Humidity: 95 %

Max PVOpen Circuit Voltage: 150 V

Max PVShort Circuit Current: 70 A

Nominal PVpower12V: 1,200 W

Nominal PVpower24V: 2,400 W

Nominal PVpower36V: 3,600 W

Nominal PVpower48V: 4,900 W

Number Of Sync Parallel Operating Units: 25

Number Of Sync Parallel Operating Units BT: 10

Number Of Trackers: 1

Pollution Degree: PD3

Programmable Relay: DPST AC rating: 240VAC / 4A, DC rating: 4A up to 35VDC, 1A up to 60VDC

Protection Category: IP22 (connection area),IP43 (electronic components)

Protections: Output short-circuit,Excessive temperature,PV reverse polarity

Rated Charge Current: 85 A

Relay Terminal Connection1: Screw terminal 3-pole

Remote On Off Terminal: Yes

Remote On Off Terminal Connection: Screw terminal two pole

Safety: CSA C22.2,EN-IEC 62109-1,UL 1741

Self Consumption: Less than 35mA @ 12V / 20mA @ 48V

Start Up PVDCVoltage: The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V

Temperature Sensor: Optional (Smart Battery Sense)

Weight: 45 kg

Width: 295 mm

Source: Victron
